MECHANICA

M3

Price base clock kit
Black varnish
9.000,- Euro

Price base clock kit
Cherry or Walnut
8.450,- Euro

  • Share on Facebook
  • Share on WhatsApp
  • Share by Mail
  • Link to Instagram

The Mechanica M3 mechanical seconds pendulum clock is the first of its kind to be available as a clock assembly kit.

It is equipped with all the technical quality features of the great clock on which it is modelled – the Erwin Sattler Classica Secunda 1985.

Make your own personal piece of history and experience precision you have created yourself – day after day, hour after hour. The effortless assembly process makes building the new M3 a real experience.

The individual components mounted on ball bearings facilitate the assembly of the complex movement, making joining the parts together a pleasure for any clock enthusiast. All the tools you need are included in your Mechanica M3 assembly kit.

To the order form

UpgradesAnniversary upgrade kitPrice list Order Forms VideoContact
  • Basic Clock Kit

    MECHANICA M3 Walnut

    Precision clock with seconds pendulum, 30 days power reserve, gold-plated brass gear wheels, hardened steel pinions, all wheels are fitted in ten stainless-steel miniature ball bearings, high-strength aluminium frame with long-lasting surface protection provided by a layer of extra-hard anodised aluminium, graham escapement with adjustable agate pallets, jewels for the pallet lever bearings, invar pendulum (temperature-compensated) with solid pendulum weight made from lacquered or nickel-plated bronze, anodised aluminium dial, bezel turned from solid brass, polished and nickel-plated to a shiny finish. bezel can alternatively be turned from solid bronze and given a baked enamel finish, blued steel hands, upon request, we can provide you with a metal plate engraved with your name to show each and every admirer who made this stunning timepiece.
    Dimensions: 1420 x 325 x 150 mm (H x W x D)

    We offer you extras under the heading “Upgrades” an.

  • Grundbausatz mit Zubehör

    MECHANICA M3 Black Varnish

    Shown with the following accessories

    UPGRADE KIT TWIN BAROMETER
    UPGRADE KIT PENDULUM LENSE
    UPGRADE KIT DIAL WITH CUTAWAY
    UPGRADE KIT POLISHED CASE-HOLDING SCREWS

    We offer you extras under the heading “Upgrades” an.

  • Grundbausatz mit Zubehör

    MECHANICA M3 Cherry

    Shown with the following accessories

    UPGRADE KIT TWIN BAROMETER
    UPGRADE KIT DIAL WITH CUTAWAY
    UPGRADE PULLEY WITH BALL BEARINGS
    UPGRADE KIT POLISHED CASE-HOLDING SCREWS

    We offer you extras under the heading “Upgrades” an.

  • BRONZE-BEZEL

    BASE CLOCK KIT DIAL

  • NICKEL-BEZEL

    BASE CLOCK KIT DIAL

  • ENGRAVING PLATE

    MECHANICA

    We offer you extras under the heading “Upgrades” an.

  • Assembly

    We offer you extras under the heading “Upgrades” an.

PreviousNext
123456789
Walnut
M3 Schwarz Abb Zubehoer
Black varnish
M3 Schwarz Abb Zubehoer
Cherry
M3 Kirschbaum Grundbausatz

BASE CLOCK KIT M3

  • Precision clock with seconds pendulum
  • 30 days power reserve
  • Gold-plated brass gear wheels
  • Hardened steel pinions.
  • All wheels are fitted in ten stainless-steel miniature ball bearings.
  • High-strength aluminium frame with long-lasting surface protection provided by a layer of extra-hard anodised aluminium.
  • Graham escapement with adjustable agate pallets.
  • Jewels for the pallet lever bearings.
  • Invar pendulum (temperature-compensated) with solid pendulum weight made from lacquered or nickel-plated bronze.
  • Anodised aluminium dial
  • Bezel turned from solid brass, polished and nickel-plated to a shiny finish. Bezel can alternatively be turned from solid bronze and given a baked enamel finish.
  • Blued steel hands
  • Upon request, we can provide you with a metal plate engraved with your name to show each and every admirer who made this stunning timepiece.
  • Dimensions: 1420 x 325 x 150 mm (H x W x D)
Mechanica

20 YEARS CLOCK KIT – UHRENBAUSATZ

Preserving existing knowledge and constantly developing it further – this principle is continued in the Erwin Sattler clock manufactory in the tradition of the clockmaker’s craft.
Knowledge and skills from the centuries-old tradition of clockmaking, coupled with state-of-the-art design and manufacturing methods, inspire people of all ages today, resulting in “timeless timepieces” that last for generations and are still proudly cherished by grandchildren.
Müller & Sattler Uhrenbausatz GmbH stands for the continuation of a traditional craft and presents

the Mechanica M3 20 year anniversary upgrade kit in a limited edition of 20 pieces!

Of course, an already purchased Mechanica M3 can also be retrofitted with this limited upgrade kit!

Müller & Sattler Uhrenbausatz GmbH stands for the continuation of a traditional craft and presents

the Mechanica M3 20 year anniversary upgrade kit in a limited edition of 20 pieces!

The anniversary upgrade kit is an assembly upgrade package that is only available with all equipment details and exclusively for the Mechanica M3.

This limited package can be purchased with a new Mechanica M3 or retrofitted to an existing Mechanica M3.

The anniversary upgrade kit includes exclusive and new equipment details:

– Moon phase with mother of pearl discs

The addition to a precision pendulum clock with the useful complication of the moon phase is also a visual highlight. The moon shines in full splendor thanks to the shimmering, hand-polished and also domed mother-of-pearl inlays.

– 24-hour display

The 24-hour display at the “6 o’clock position” can also be used as a second time zone.
It is a practical addition for keeping an eye on the time in other parts of the world. Purists appreciate it as an astronomical hour marker.

– Central hours and minutes display

The classic clock dial – is now available for the first time on the Mechanica M3 and, in view of the additional displays, makes it easier to read the time.

– 4-part, domed hands set

The domed, polished and blued hands are completely hand crafted. They will give your Mechanica a more elegant “face”.

– Cutaway in the dial

The cutaway in the seconds subdial in conjunction with a milling in the top plate of the movement makes it possible to see natural anodized plates, the gold-plated gear wheels and the Graham escapement.

PreviousNext

Dial numbers of the limited upgrade kit for the Mechanica M3

X
X
X
X
X
X
X
8
9
X
11
12
X
14
15
X
17
18
19
X

Prices

– Price of the upgrade kit for a new order of a Mechanica M3: 3.800,- Euro

– Price of the upgrade kit for subsequent orders: 5.300,- Euro, a refund on return of the original parts is not possible with this upgrade kit.

Contents of the upgrade kit: 2 x plates (natural anodized), dial with cutaway, motion work and domed hands set for central display, 24h module, moon module.

PRICES

NEW PURCHASE

New order of a Mechanica M3
Price anniversary upgrade kit 3.800,- €

Order form

SUBSEQUENT PURCHASE

Subsequent order
Price anniversary upgrade kit 5.300,- €

Order form

* For subsequent orders, a reduced price is not possible by returning the standard parts.

Contents of the upgrade kit:

2 x plates (natural anodized), dial with cutaway, motion work and domed hands set for central display, 24h module, moon module.

MECHANICA M3 Upgrades

To give you the opportunity to upgrade your new Mechanica M3 both technically and visually, various accessories were already considered when planning the kit. With the following extras, you can customise your Mechanica M3 in terms of durability, accuracy and appearance.

UPGRADE KIT

TWIN BAROMETER

To compensate for the negative impact of the air pressure fluctuations on the accuracy of the clock, a barometer with aneroid capsules is available.

Price 1.050,– Euro

UPGRADE KIT

PULLEY WITH BALL BEARINGS

The ball-bearing rope pulley offers not only visual appeal but also two technical advantages: Its ball bearings do not wear and they keep frictional losses to a minimum, which improves the accuracy of the clock.

Price 335,– Euro
Reduced Price 300,– Euro*

M3 Zubehör Zeiger

UPGRADE KIT

HAND-DOMED AND POLISHED HANDS

The hands have been painstakingly “domed”, polished and blued by hand to lend the dial even greater elegance.

Price 560,– Euro
Reduced Price 520,– Euro*

UPGRADE KIT

BEVELLED GLASSES

All three panes of glass have polished bevelled edges that lend the case even more elegance.

Price 410,– Euro

M3 Zifferbllat Vorderplatine

UPGRADE KIT

DIAL WITH CUTAWAY

The cutaway in the seconds dial and the recess in the front plate of the movement allow a view of the gold-plated gear wheels and the Graham escapement. The upgrade set contains the dial with cutaway and the recessed front plate with cutaway.

Price 1.050,– Euro
Reduced Price 930,– Euro*

UPGRADE KIT

PENDULUM LENS

A solid pendulum lens can be ordered as
an optional extra for the pendulum. The fact that there is less air resistance means that the amplitude of oscillation, and consequently the rate, remain steadier. The lenses are numbered in sequence and can be fitted with the engraving either at the
front or at the back. The lens is available in
bronze or nickel finish.

Price 1.000,– Euro
Reduced Price 940,– Euro*

CERTIFICATED WEIGHTS FOR FINE REGULATION

With the certificated set of twelve weights an even more exact fine regulation is possible.

Price without wooden case 175,– Euro
Elegant wooden case with magnetic closure 95,– Euro

Details

UPGRADE KIT

SET OF FINE-POLISHED SCREWS

A further detail to add an elegant appearance to your M3, are the four case fitting screws with polished and blued
center and two polished movement fixing screws.

Price 260,– Euro
Reduced Price 240,– Euro*

UPGRADE KIT

GLASS WINDOW IN THE TOP OF THE CASE

Incorporating a pane of mineral glass into the top allows a spotlight to illuminate the movement.

Price 420,– Euro

.

SATTLER varnish

The quality of the standard varnish can
be increased by applying much more layers
of high quality resin-varnish which is
sanded several times. This surface has a higher hardness and a deeper black color.

Price 960,– Euro

M3

UPGRADE KIT

DOUBLE CYLINDER PENDULUM

According to Ludwig Strasser.

BICOLOR OR NICKEL-PLATED
Price 1.050,– Euro
Reduced Price 990,– Euro*

UPGRADE KIT

SET OF FINE-POLISHED SCREWS

The look of the movement can be further enhanced using these 4 gold-plated
washers and the 24 fine-polished/
fine-turned stainless-steel screws.

Price 270,– Euro
Reduced Price 260,– Euro*

ASSEMBLY BY THE MANUFACTURE

Price 700,– Euro

MECHANICA M3 assembly instructions

In the „clock book“ that comes with every kit, you can read more about evolution and technology of mechanic clocks. Linen bound and printed on high quality paper.

Lean back and take some time. A complete version of the book is available as PDF. The first chapter ist the complete instruction. The second chapter explains the technology and function of the Mechanica M3.

You will additionally find the assembly instructions for the Mechanica M3 – 20 years conversion kit here.

‘The Clock Book’ contains detailed assembly instructions and a technical description of the Mechanica M3.

The assembly instructions in the book for the Mechanica M3 clock kit.pdf | 4 MB

Supplementary assembly instructions for the Mechanica M3 conversion kit – 20 years, for a new order.

Assembly instructions Mechanica M3 conversion kit for a new order.pdf | 6 MB

UpgradesAnniversary upgrade kitPrice list Order Forms VideoContact
M3 Grundbausatz Nuss

MECHANICA M3
basic clock kit

Price List

Mechanica M3

MECHANICA M3 Price Reduced price*
MECHANICA M3 Clock kit | Black Varnish€ 9.000.-
MECHANICA M3 Clock kit | Cherry or Walnut€ 8.450.-
UPGRADE KIT TWIN BAROMETER
To compensate for the negative impact of the air pressure fluctuations on the accuracy of the clock, a barometer with aneroid capsules is available.
€ 1.050.-
UPGRADE KIT PULLEY WITH BALL BEARINGS
The ball-bearing rope pulley offers not only visual appeal but also two technical advantages: Its ball bearings do not wear and they keep frictional losses to a minimum, which improves the accuracy of the clock.
€ 335.- € 300.-
UPGRADE KIT HAND-DOMED AND POLISHED HANDS
The hands have been painstakingly “domed”, polished and blued by hand to lend the dial even greater elegance.
€ 560.- € 520.-
UPGRADE KIT BEVELLED GLASSES
All three panes of glass have polished bevelled edges that lend the case even more elegance.
€ 410.-
UPGRADE KIT DIAL WITH CUTAWAY
The cutaway in the seconds dial and the recess in the front plate of the movement allow a view of the gold-plated gear wheels and the Graham escapement. The upgrade set contains the dial with cutaway and the recessed front plate with cutaway.
€ 1.050.- € 930.-
UPGRADE KIT PENDULUM LENS
A solid pendulum lens can be ordered as an optional extra for the pendulum. The fact that there is less air resistance means that the amplitude of oscillation, and consequently the rate, remain steadier. The lenses are numbered in sequence and can be fitted with the engraving either at the front or at the back. The lens is available in bronze or nickel finish.
€ 1.000.- € 940.-
CERTIFICATED WEIGHTS FOR FINE REGULATION
With the certificated set of twelve weights an even more exact fine regulation is possible.
Price without wooden case 175,– Euro

Elegant wooden case with magnetic closure 95,– Euro

UPGRADE KIT SET OF FINE-POLISHED SCREWS
The look of the movement can be further enhanced using these 4 gold-plated washers and the 24 fine-polished/fine-turned stainless-steel screws.
€ 260.- € 240.-
UPGRADE KIT GLASS WINDOW IN THE TOP OF THE CASE
Incorporating a pane of mineral glass into the top allows a spotlight to illuminate the movement.
€ 420.-
SATTLER varnish
Possibility to equip the case of the Mechanica M3 with a more exclusive surface.
€ 960.-
UPGRADE KIT DOUBLE CYLINDER PENDULUM
According to Ludwig Strasser.
BICOLOR OR NICKEL-PLATED
€ 1.050.-€ 990.-
UPGRADE KIT SET OF FINE-POLISHED SCREWS
The look of the movement can be further enhanced using these 4 gold-plated washers and the 24 fine-polished/fine-turned stainless-steel screws.
€ 270.- € 260.-
ASSEMBLY BY THE MANUFACTURE€ 700.-

Prices incl. 19% VAT.
(* Reduced price – new order with retention/return of standard parts.)

Mechanica M3

Price list

  • MECHANICA M3 Clock kit | Black Varnish
    € 8300.-
  • MECHANICA M3 Clock kit | Cherry or Walnut
    € 7800.-
  • UPGRADE KIT TWIN BAROMETER
    € 980.-
  • UPGRADE KIT PULLEY WITH BALL BEARINGS
    € 310.- | reduced price € 280.-
  • UPGRADE KIT HAND-DOMED AND POLISHED HANDS
    € 520.- | reduced price € 480.-
  • UPGRADE KIT BEVELLED GLASSES
    € 380.-
  • UPGRADE KIT DIAL WITH CUTAWAY
    € 980.- | reduced price € 860.-
  • UPGRADE KIT PENDULUM LENSE
    € 930.- | reduced price € 870.-
  • CERTIFICATED WEIGHTS FOR FINE REGULATION
    Price without wooden case 165,– Euro
    Elegant wooden case with magnetic closure 85,– Euro
  • UPGRADE KIT SET OF FINE-POLISHED SCREWS
    € 240.- | reduced price € 220.-
  • UPGRADE KIT GLASS WINDOW IN THE TOP OF THE CASE
    € 390.-
  • SATTLER-LACK
    € 890.-
  • UPGRADE KIT DOUBLE CYLINDER PENDULUM
    € 980.- | reduced price € 900.-
  • UPGRADE KIT SET OF FINE-POLISHED SCREWS
    € 250.- | reduced price € 240.-
  • ASSEMBLY BY THE MANUFACTURE
    € 400.-

Prices include 19% value added tax. Delivery within Germany is free of charge.
(*Reduced price if the faultless original parts are returned or if a new order is placed)

Order forms

Mechanica M3

PDF order form for the clock kit Mechanica M3

New orders, optionally with accessories, reduced prices with retention/return of standard parts

PDF order form for the clock kit Mechanica M3

New order, optionally with accessories, regular prices without retention/return of the standard parts

PDF order form for clock kit Mechanica M3 including 20th anniversary upgrade kit

New orders, optionally with accessories, reduced prices with retention/return of standard parts

PDF order form for the 20th anniversary upgrade kit for the Mechanica M3

Subsequent order of the 20th anniversary upgrade kit for the Mechanica M3, regular price without return of standard parts

Terms and conditions

Order forms

Mechanica M3

PDF order form with calculation function for the clock kit Mechanica M3

New orders, optionally with accessories, reduced prices with retention/return of standard parts

PDF order form with calculation function for the clock kit Mechanica M3

New order, optionally with accessories, regular prices without retention/return of the standard parts

Order forms for Safari users

(the calculation function is not supported by Safari!)
Mechanica M3

PDF order form without calculation function for the clock kit Mechanica M3

New orders, optionally with accessories, reduced prices with retention/return of standard parts

PDF order form without calculation function for the clock kit Mechanica M3

New order, optionally with accessories, regular prices without retention/return of the standard parts

Terms and conditions

MECHANICA M3

The Mechanica M3 mechanical seconds pendulum clock is the first of its kind to be available as a clock assembly kit. Let yourself be inspired!

Contact us

If you have any questions about our clock kit products, we are happy to help you with advice and support. Please use the following contact form, we will answer you as soon as possible.







    Müller & Sattler Uhrenbausatz GmbH

    Lohenstraße 6
    82166 Gräfelfing
    Germany

    • info (at) uhrenbausatz.de
    • +49 (0)89 8955806-20
    • Contact
    • Where we are

    SUBSCRIBE NOW

    Yes, I want to be informed about
    news by Uhrenbausatz.

    email

    By subscribing, I confirm that I have read and accepted the Privacy Policy and that I would like to receive information by Uhrenbausatz using any of the communication method(s) that I have provided above.

    Service

    +49 (0)89 8955806-0

    • Monday - Friday
      9:00 a.m. to 4:00 p.m.
    • Visiting appointments only by prior arrangement by phone or email.
      We ask for your understanding!

    Social Media

    instagram facebook

    © Copyright - UHRENBAUSATZ Your personal piece of contemporary history
    • Newsletter
    • Privacy Policy
    • Site Notice
    • Terms and Conditions
    Scroll to top
